Description
Troubleshoot hot spots, find hidden faults, and confirm repairs quickly with the ergonomic, high-resolution FLIR T540. This 161,472 (464 × 348) pixel thermal imaging camera has a bright 4″ LCD and a 180° rotating lens platform, so you can easily and comfortably diagnose electrical or mechanical issues, even in hard-to-reach areas. Advanced on-camera measurement tools such as 1-Touch Level/Span, plus laser-assisted autofocus, ensure you’ll record accurate temperature measurements every time. Add the Inspection Route camera option, and you can download and run survey plans to your camera from FLIR Thermal Studio Pro (with with Route Creator plugin). Together these systems will help you record temperature data and imagery in a logical sequence for faster troubleshooting and repair.
Resolution, Comfort, And Outstanding Performance
-
MAKE CRITICAL DECISIONS QUICKLY
Laser-assisted autofocus guarantees you’ll get tack-sharp focus for accurate temperature readings that lead to quick but solid decisions.
-
FLEXIBLE AND ERGONOMIC
The T540’s optical block rotates 180°, so you can image targets at any angle—comfortably—all day long.
-
INTUITIVE USER INTERFACE
The capacitive touchscreen with intuitive menu is easy to navigate, plus you can customize with two programmable buttons.
SPECIFICATIONS
OVERVIEW
- Accuracy
- ±2°C (±3.6°F) or ±2% of reading
- Color alarm (isotherm)
- •Above •Below •Interval •Condensation (moisture/humidity/dewpoint) •Insulation
- Difference Temperature
- Yes
- Display Technology
- IPS
- Focal Length
- 17 mm (0.67 in.), 24°
- Housing material
- PCABS with TPE, magnesium
- IR Resolution
- 464 × 348 pixels
- Laser Alignment
- Position is automatically displayed on the infrared image
- Laser Pointer
- Class 2, 0.05–40 m (0.16–131 ft.) ±1% of measured distance
- NETD
- <40 mK
- Object Temperature Range
- -20°C to 120°C (-4°F to 248°F) 0°C to 650°C (32°F to 1202°F) 300°C to 1500°C (572°F to 2732°F) There are no optional ranges
- Packaging Size
- 500 × 190 × 370 mm (19.7 × 7.5 × 14.6 in.)
- Programmable Buttons
- 2
- Resolution
- 464 × 348 pixels (VGA)
- Screening
- 0.5°C (0.9°F) accuracy at 37°C (98.6°F) with reference
- Size (L x W x H)
- Lens horizontal: 140 × 201.3 × 167.3 mm (5.5 × 7.9 × 6.6 in.)
- Thermal Sensitivity/NETD
- <40 mK, 24° @ 30°C (86°F)
- Warranty
- http://www.flir.com/warranty/
- Text
- Predefined list or touchscreen keyboard
- Time Lapse [Infrared]
- 10 sec to 24 hrs
- Voice
- 60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth
- Weight & Dimensions (without lens)
- 1.3 kg (2.9 lbs), 140 × 201 × 84 mm (5.5 × 7.9 × 3.3 in)
CONNECTIONS & COMMUNICATIONS
- Audio
- Microphone and speaker for voice annotation of images
- Communication Interfaces
- USB 2.0, Bluetooth, Wi-Fi
- METERLiNK – Bluetooth
- Communication with headset and external sensors
- Remote Control
- •Using FLIR Tools (using USB cable) •FLIR Tools Mobile (over Wi-Fi)
- Storage Media
- Removable SD card
- USB
- USB Type-C: data transfer/video/power
- USB – Standard
- USB 2.0 High Speed
- Video Out
- DisplayPort over USB Type-C
- METERLiNK
- Wireless connection (Bluetooth) to: FLIR meters with METERLiNK
- Setup Commands
- Local adaptation of units, language, date, and time formats
ENVIRONMENTAL
- EMC
- •ETSI EN 301 489-1 (radio) •ETSI EN 301 489-17 •EN 61000-6-2 (immunity) •EN 61000-6-3 (emission) •FCC 47 CFR Part 15 Class B (emission)
- Emissivity Correction
- Yes, variable from 0.01 to 1.0 or selected from materials list
- Humidity (Operating and Storage)
- IEC 60068-2-30/24 hours, 95% relative humidity, 25–40°C (77–104°F)/2 cycles
- Operating Temperature Range
- –15°C to 50°C (5°F to 122°F)
- Radio Spectrum
- •ETSI EN 300 228 •FCC Part 15.249 •RSS-247 Issue 2
- Safety
- EN/UL/CSA/PSE 60950-1
- Storage Temperature Range
- –40°C to 70°C (-40°F to 158°F)
- Tripod Mounting
- UNC 1/4″-20
- Shock & Vibration & Encapsulation
- 25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6 / IP 54; EN/UL/CSA/PSE 60950-1
IMAGING & OPTICAL
- Aspect ratio
- 4:3
- Auto Rotation
- Yes
- Camera software update
- Use PC software FLIR Tools
- Color
- Black
- Color palettes
- Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
- Detector Type and Pitch
- Uncooled microbolometer, 17 µm
- Digital Camera
- 5 MP, with built-in LED photo/video lamp
- Digital Camera Focus
- Fixed
- Digital Camera FOV
- 53° × 41°
- Digital Zoom
- 1–6× continuous
- f-number
- 1.3, 24°
- Field of View
- 24° × 18°
- Field of view match
- Yes
- Focus
- Continuous with laser distance meter (LDM), one- shot LDM, one-shot contrast, manual
- Frame Rate [Full Window]
- 30 Hz
- Gallery
- Yes
- Global Positioning System [GPS]
- Location data automatically added to every still image and first frame in video from built-in GPS
- Image Adjustment
- •Automatic •Automatic maximum •Automatic minimum •Manual
- Image Frequency
- 30 Hz
- Image Sketch
- From touchscreen, on infrared image only
- Lens
- 24°
- Lens Identification
- Automatic
- Minimum Foc
